Extra Capabilities for new Applications
Listed below is a summary of the expanded command sets available for new applications. refer to
the Appendix B, page 118 through 124 for details of using the expanded command sets.
PCL3+ Mode
This operation mode provides the following extended capabilities:
PCL3+D Mode
This mode provides all of the capabilities described above plus the following:
Saving Your Setup
Once you have completed your printer set-up, the configuration can be saved as a User setup.
Use the printer's Extended Setup menu 86 SAVE SETUP and save your setting as either MEMO 1,
MEMO 2, or MEMO 3.
This saved setup may be re-initialized at any time using 8 SELECT SETUP to select the applicable
User setup MEMO 1, MEMO 2, or MEMO 3.
Escape
Description Added Capability:
Command
BEL Activates the printer's bell Bell is now active
ESC & k # W Controls the print direction
Unidirectional, Bidirectional, Predirectional
ESC ( # id Assign the primary font PC-850, ISO25, France 2, German2,
Spain 3, Legal, Math7, Math-Symbol,
ISO84 Portugal 2, ISO85 Spain 2
ESC ) # id Assign the secondary font PC-850, ISO25, France 2, German2,
Spain 3, Legal, Math7, Math-Symbol,
ISO84 Portugal 2, ISO85 Spain 2
ESC ( s # H Sets the character pitch 15, 17.1, 24 cpi
(primary)
ESC ) s # H Sets the character pitch 15, 17.1, 24 cpi
(secondary)
ESC ( s # T Sets the primary typeface Script, Orator, Orator-s, OCR-A, OCR-B
ESC ) s # T Sets the secondary typeface Script, Orator, Orator-s, OCR-A, OCR-B
ESC * b # M
Select graphics data compression
Off, Mode1, Mode2, Mode3
ESC * t # R
Designates raster graphics resolution
60, 360 dpi
Escape
Description Added Capability:
Command
ESC * p # X Sets horizontal positioning by dot 1/360"
ESC * p # Y Sets vertical positioning by dot 1/360"
59
