Seiko 5M84A - Parts List - Calendar and Dial Components; Calendar Mechanism and Dial Parts

26
27
28
0012354
DAY LEVER GUARD SCREW
0837503
DAY LEVER GUARD
1002516
DAY WHEEL
1017503
DAY LEVER
1018504
DAY LEVER SPRING
0871502
DAY STAR WHEEL
0491735
DIAL WASHER
0022247
DAY LEVER BRIDGE SCREW
0808514
DATE DIAL GUARD
0878***
DATE DIAL
0810660
DATE JUMPER
0989660
INTERMEDIATE DAY CORRECTOR WHEEL
0737670
DATE CORRECTOR WHEEL
0962670
INTERMEDIATE DATE CORRECTOR WHEEL
0816670
DATE DRIVING WHEEL
0271607
HOUR WHEEL
DAY LEVER BRIDGE
HOLDING RING FOR DIAL
0866***
11
12
14
15
16
17
18
19
20
21
22
23
24
25
SPACER FOR DIAL
10
4408564
4408559
X
II
I
II
I
I
I
I
I
I
I
I
I
V
VI
V
V
I
I
I
XI
X
XI
SEIKO
PRE MIER
KIN ET IC
MON
TUE
WED
THU
FRI
SAT
SUN
RETROGRADE DAY HAND
DIAL
HOUR, MINUTE AND SECOND HANDS
9
8
13
Cal. 5M84A
4/21
PARTS LIST
Please see the remarks on the following pages.
Lubricatingofsomepartsisshownin“II.REMARKSONDISASSEMBLINGANDREASSEMBLING”.
[CALENDAR MECHANISM/
DIAL AND HANDS SETTING]
