Seiko 5M84A - Parts List - Casing Components; Casing Parts Assembly

Cal. 5M84A
3/21
PARTS LIST
Disassembling procedures Figs. : 1 65
Reassembling procedures Figs. : 65 1
Lubricating: Types of oil
Watch Oil AO-3
Watch Oil AO-2
 SEIKOWatchOilS-6
 Siliconeoil500,000c.s.
Oil quantity
 Normalquantity
Please see the remarks on the following pages.
Lubricatingofsomepartsisshownin“II.REMARKSONDISASSEMBLINGANDREASSEMBLING”.
 1 CASEBACK
 2 CASEBACKGASKET
 4 MOVEMENT
 7 BUTTONSPRING
 5 BUTTONSPRINGCLIP
6 BUTTON
3 CROWN
[CASING PARTS ASSEMBLY]
