Cal. 5M84A
7/21
PARTS LIST
l
How to find the correct parts, if not determined by 4 digit caliber number
Following parts are determined based on the design of watches, such as hands height, dial color,
and design of cases. Please refer to the SEIKO WATCH PARTS CATALOGUE in order to choose
corresponding parts.
Remarks
0022247
• DAYLEVERBRIDGESCREW (3PCS.)
• RECHARGEABLEBATTERYCLAMPSCREW(2PCS.)
• CIRCUITBLOCKCOVERSCREW (2PCS.)
• OSCILLATINGWEIGHTBRIDGESCREW(2PCS.)
• COILBLOCKSCREW (1PC.)
• TRAINWHEELBRIDGESCREW (1PC.)
0022490
• OSCILLATINGWEIGHTSCREW (1PC.)
0012354
• DAYLEVERGUARDSCREW  (1PC.)
 11 HOLDINGRINGFORDIAL0866***
22 DATEDIAL
Part code Position of crown
Position of calendar
frame
Colorofgure Color of back ground
0878B42 3 o'clock 3 o'clock White Black
0878B43 3 o'clock 3 o'clock Black White
0878 B25 3 o'clock 6 o'clock White Black
0878 B26 3 o'clock 6 o'clock Black White
62 SETTINGSTEM0351653
ThetypeofSETTINGSTEMisdeterminedbasedonthedesignofcases.
CheckthecasenumberandrefertoSEIKOCasingPartsCataloguetochooseacorrespondingpart.
SCREWS
