Seiko 7D56A - PARTS LIST: CALENDAR UNIT (3); Piezoelectric Motor Components

34
MONTH INDICATOR
WHEELJUMPER
1024 504
35
INTERMEDIATE MONTH
INDICATOR WHEEL
SPRING
1024 503
36
DA
TE JUMPER FOR
TEN’S DIGIT
1024 501
Positioning pin A for spring
for intermediate wheel
for indicator for month
To be set for assembling
29
1ST INTERMEDIATE DATE WHEEL
0817 512
30
PIEZOELECTRIC ROTOR BLOCK
4146 514
31
INSULATOR FOR
PIEZOELECTRIC MOTOR
4216 540
32
PIEZOELECTRIC MOTOR CONDUCTIVE PLATE
0105 502
33
PIEZOELECTRIC STATOR BLOCK
4583 500
[CALENDAR UNIT (3)]
Please refer to the remarks on the following pages.
Lubricating of some parts is shown in “ REMARKS ON DISASSEMBLING AND REASSEMBLING
THE MOVEMENT.”
Cal. 7D56A
8/44
PARTS LIST
