Seiko 7D56A - PARTS LIST: CALENDAR UNIT (4); Calendar Corrector and Circuit Block

45
CIRCUIT BLOCK FOR
CALENDAR
4000 669
37
CALENDAR PLATE
4408 563
38
DATE DRIVING WHEEL
FOR TEN'S DIGIT
0802 506
39
DATE PINION
FOR TEN'S DIGIT
1013 504
40
CALENDAR CORRECTOR
3RD INTERMEDIATE WHEEL
0962 501
41
CALENDAR CORRECTOR
4TH INTERMEDIATE
WHEEL
0962 502
43
3RD INTERMEDIATE DATE
WHEEL
0817 514
44
HOUR WHEEL
0271 564
46
CONNECTOR B
4313 582
47
CONNECTOR A
4313 581
48
PIEZOELECTRIC MOTOR
SETTING LEVER
0981 500
49
CONTROL WHEEL
JUMPER
1024 502
42
CALENDAR CORRECTOR
2ND INTERMEDIATE WHEEL
0962 559
50
EARTHING SPRING
4281 510
[CALENDAR UNIT (4)]
Please refer to the remarks on the following pages.
Lubricating of some parts is shown in “ REMARKS ON DISASSEMBLING AND REASSEMBLING
THE MOVEMENT.”
Cal. 7D56A
9/44
PARTS LIST
