2.5 Connecting the Printer
Connection
1. Turn off the printer and computer.
2. Connect the printer to the computer with an interface cable.
Parallel: Secure with veil lock.
Serial: Secure with screws.
3. Set the printer SWDIP switches to match the input method.
4. Turn on the printer and the computer.
 Select the correct interface cable for the type of input (parallel or
serial).
Connectors:
Parallel : Anphenol 36-pin
Equipped connector
: 57LE-40360-7700(D29)(DDK) or equivalent
Serial: D-Subminiature type connector with 9-pin
Equipped connector
: (M2.6 type) RDED-9SE-LN(05) (HIROSE)
or equivalent
 Use a shielded cable no more than 1.5m long.
NOTE
Confirmation
Follow the instructions in section 2.8, Printing, to confirm that the printer
is connected properly.
