(3) Data Input Timing
(Unit: s, typical)
5.3
4.8
1.0
0.5 Min.
0.5 Min.
0.5 Min.
DATA 0
DATA 7
STROBE
BUSY
A
CK
(4) Signal Conditions
Standard
Item
Min. Typ. Max.
Unit
Input: Low Level Voltage 0.0

0.9 V
Input: High Level Voltage 3.5

5.0 V
Output: Low Level Voltage
 
0.5 V
Output: High Level Voltage 3.5
 
V
