Seitron TDST24M - P3: Antifrost Parameter Management

12
TDST24M000SE 032635 190619
Antifrost temperature
Data Regulation range Default
TAF -10.0°C .. +10.0 °C 4.0 °C
Collector pump ‘on’ time
Data Regulation range Default
P OF 1 .. 60 min. 20 min.
Collector pump ‘off’ time
Data Regulation range Default
P ON 5 .. 60 sec. 10 sec.
Antifrost test duration
Data Regulation range Default
TMR 5 .. 60 sec. 10 sec.
IT IS POSSIBLE TO SCROLL CYCLICALLY THROUGH
ANTIFROST DATA USING THE ‘  ‘ OR ‘  ‘ ARROWS:
- Antifrost temperature ‘ TAF ’
- Collector pump ignition interval ‘ P ON ’
- Collector pump shut off interval ‘ P OF ’
- Antifrost test duration ‘ TMR ’

AFTER SELECTING PARAMETER P3 PRESS
THE ‘  ‘ KEY.


USE THE ‘  ‘ OR ‘  ‘ ARROWS TO SET THE
DESIRED NUMERIC VALUE.
PRESS THE ‘  ‘ KEY TO CONFIRM THE PROGRAMMING
OR PRESS THE ‘ esc ’ KEY TO CANCEL THE CHANGES.

PRESS THE ‘  ‘ KEY TO MODIFY THE THERMAL DATA
SELECTED; THE DATA WILL START FLASHING.

BY PRESSING THE ‘  ‘ KEY AFTER MODIFYING
THE DATA RELATIVE TO THE DURATION OF THE
ANTIFROST TEST, THE CONTROL UNIT WILL CONFIRM
THE DATA AND WILL START THE TEST.
P3: ANTIFROST PARAMETER MANAGEMENT
Using this parameter it is possible to set the data managing
the antifrost function.
The control unit is supplied with preset antifrost data
for optimal operation.
Any change to these values must be performed by
qualied personnel only.
In the following the regulation ranges allowed for each
parameter are listed.
