SEL-411L Data Sheet Schweitzer Engineering Laboratories, Inc.
36
PTP—Ethernet Port 5A, 5B
Input: IEEE 1588 PTPv2
Profiles: Default, C37.238-2011 (Power Profile),
IEC/IEEE 61850-9-3-2016 (Power Utility
Automation Profile)
Synchronization Accuracy: ±100 ns @ 1-second synchronization
intervals when communicating directly
with master clock
Operating Temperature
–40° to +85°C (–40° to +185°F)
Control Outputs: As many as 30 outputs can be energized
at or below 40°C ambient.
Note: LCD contrast impaired for temperatures below –20° and above +70°C
Humidity
5% to 95% without condensation
Overvoltage Category
Category II
Insulation Class
I
Pollution Degree
2
Weight (Maximum)
4U Rack Unit: 10.3 kg (22.8 lb)
5U Rack Unit: 12.0 kg (26.4 lb)
6U Rack Unit: 13.5 kg (29.8 lb)
7U Rack Unit: 15.3 kg (33.7 lb)
Terminal Connections
Rear Screw-Terminal Tightening Torque, #8 Ring Lug
Minimum: 1.0 Nm (9 in-lb)
Maximum: 2.0 Nm (18 in-lb)
User terminals and stranded copper wire should have a minimum
temperature rating of 105°C. Ring terminals are recommended.
Wire Sizes and Insulation
Wire sizes for grounding (earthing), current, voltage, and contact
connections are dictated by the terminal blocks and expected load
currents. You can use the following table as a guide in selecting wire
sizes. The grounding conductor should be as short as possible and sized
equal to or greater than any other conductor connected to the device,
unless otherwise required by local or national wiring regulations.
Connection Type Min. Wire Size Max. Wire Size
Grounding (Earthing)
Connection
14 AWG (2.5 mm
2
)N/A
Current Connection 16 AWG (1.5 mm
2
) 10 AWG (5.3 mm
2
)
Potential (Voltage)
Connection
18 AWG (0.8 mm
2
) 14 AWG (2.5 mm
2
)
Contact I/O 18 AWG (0.8 mm
2
) 10 AWG (5.3 mm
2
)
Other Connection 18 AWG (0.8 mm
2
) 10 AWG (5.3 mm
2
)
Type Tests
Installation Requirements
Overvoltage Category: 3
Pollution Degree: 2
Safety
Product Standards IEC 60255-27:2013
IEEE C37.90-2005
21 CFR 1040.10
Dielectric Strength: IEC 60255-27:2013, Section 10.6.4.3
2.5 kVac, 50/60 Hz for 1 min: analog
inputs, contact outputs, digital inputs
3.6 kVdc for 1 min: power supply, battery
monitors
2.2 kVdc for 1 min: IRIG-B
1.1 kVdc for 1 min: Ethernet
Impulse Withstand: IEC 60255-27:2013, Section 10.6.4.2
IEEE C37.90-2005
Common Mode:
±1.0 kV: Ethernet
±2.5 kV: IRIG-B
±5.0 kV: all other ports
Differential Mode:
0 kV: analog inputs, Ethernet, IRIG-B,
digital inputs
±5.0 kV: standard contact outputs,
power supply battery monitors
+5.0 kV: hybrid contact outputs
Insulation Resistance: IEC 60255-27:2013, Section 10.6.4.4
>100 M @ 500 Vdc
Protective Bonding: IEC 60255-27:2013, Section 10.6.4.5.2
<0.1 @ 12 Vdc, 30 A for 1 min
Object Penetration: IEC 60529:2001 + CRGD:2003
Protection Class: IP30
Max Temperature of Parts
and Materials: IEC 60255-27:2013, Section 7.3
Flammability of Insulating
Materials:
IEC 60255-27:2013, Section 7.6
Compliant
Laser Safety: IEC 60825-1:2007
21 CFR 1040.10 Class 1
Electromagnetic (EMC) Immunity
Product Standards: IEC 60255-26:2013
IEC 60255-27:2013
IEEE C37.90-2005
Surge Withstand Capability
(SWC):
IEC 61000-4-18:2006 + A:2010
IEEE C37.90.1-2012
Slow Damped Oscillatory, Common and
Differential Mode:
±1.0 kV
±2.5 kV
Fast Transient, Common and Differential
Mode:
±4.0 kV
Electrostatic Discharge
(ESD):
IEC 61000-4-2:2008
IEEE C37.90.3-2001
Contact:
±8 kV
Air Discharge:
±15 kV
