Schweitzer Engineering Laboratories, Inc. SEL-411L Data Sheet
37
Radiated RF Immunity: IEEE C37.90.2-2004
IEC 61000-4-3:2006 + A1:2007 + A2:2010
20 V/m (>35 V/m, 80% AM, 1 kHz)
Sweep: 80 MHz to 1 GHz
Spot: 80, 160, 450, 900 MHz
10 V/m (>15 V/m, 80% AM, 1 kHz)
Sweep: 80 MHz to 1 GHz
Sweep: 1.4 GHz to 2.7 GHz
Spot: 80, 160, 380, 450, 900, 1850,
2150 MHz
Electrical Fast Transient
Burst (EFTB):
IEC 61000-4-4:2012
Zone A:
±2 kV: communication ports
±4 kV: all other ports
Surge Immunity: IEC 61000-4-5:2005
Zone A:
±2 kV
L-L
±4 kV
L-E
±4 kV: communication ports (Ethernet)
Note: Cables connected to EIA-422, G.703,
EIA-232, and IRIG-B communications
ports shall be less than 10 m in length for
Zone A compliance.
Zone B:
±1 kV
L-L
: 24–48 Vdc power supply
±2 kV
L-E
: 24–48 Vdc power supply
±2 kV: communication ports (except
Ethernet)
Note: Cables connected to EIA-232
communications ports shall be less than 10
m in length for Zone B compliance.
Conducted Immunity: IEC 61000-4-6:2013
20 V/m; (>35 V/m, 80% AM, 1 kHz)
Sweep: 150 kHz–80 MHz
Spot: 27, 68 MHz
Power Frequency Immunity
(DC Inputs):
IEC 61000-4-16:2015
Zone A:
Differential: 150 V
RMS
Common Mode: 300 V
RMS
Power Frequency Magnetic
Field:
IEC 61000-4-8:2009
Level 5:
100 A/m; 60 seconds; 50/60 Hz
1000 A/m 1 to 3 seconds; 50/60 Hz
Note: 50G1P 0.05 (ESS = N, 1, 2)
50G1P 0.1 (ESS = 3, 4)
Power Supply Immunity: IEC 61000-4-11:2004
IEC 61000-4-17:1999/A1:2001/A2:2008
IEC 61000-4-29:2000
AC Dips & Interruptions
Ripple on DC Power Input
DC Dips & Interruptions
Gradual Shutdown/Startup (DC only)
Discharge of Capacitors
Slow Ramp Down/Up
Reverse Polarity (DC only)
Damped Oscillatory
Magnetic Field:
IEC 61000-4-10:2016
Level 5:
100 A/m
EMC Compatibility
Product Standards: IEC 60255-26:2013
Emissions: IEC 60255-26:2013, Section 7.1
Class A
47 CFR Part 15B
Class A
Canada ICES-001 (A) / NMB-001 (A)
Environmental
Product Standards: IEC 60255-27:2013
Cold, Operational: IEC 60068-2-1:2007
Test Ad: 16 hours at –40°C
Cold, Storage: IEC 60068-2-1:2007
Test Ad: 16 hours at –40°C
Dry Heat, Operational: IEC 60068-2-2:2007
Test Bd: 16 hours at +85°C
Dry Heat, Storage: IEC 60068-2-2:2007
Test Bd: 16 hours at +85°C
Damp Heat, Cyclic: IEC 60068-2-30:2005
Test Db: +25°C to +55°C, 6 cycles (12 +
12-hour cycle), 95% RH
Damp Heat, Steady State: IEC 60068-2-78:2013
Severity: 93% RH, +40°C, 10 days
Cyclic Temperature: IEC 60068-2-14:2009
Test Nb: –40 °C to +80°C, 5 cycles
Vibration Resistance: IEC 60255-21-1:1988
Class 2 Endurance, Class 2 Response
Shock Resistance: IEC 60255-21-2:1988
Class 1 Shock Withstand, Class 1 Bump
Withstand, Class 2 Shock Response
Seismic: IEC 60255-21-3:1993
Class 2 Quake Response
Reporting Functions
Traveling-Wave Fault Location
Application: Two terminal lines with high-accuracy time
sources
Method: Double-ended traveling wave
Sampling Rate: 1.5625 MHz
Device Accuracy: ±25 meters for a step change in current
applied simultaneously to both relays
Application Accuracy: 300 m typical
Output Format: Binary COMTRADE
High-Resolution Data
Rate: 8000 samples/second
4000 samples/second
2000 samples/second
1000 samples/second
Output Format: Binary COMTRADE
Note: Per IEEE Std C37.111-1999 and C37.111-2013, Common Format for
Transient Data Exchange (COMTRADE) for Power Systems.
Event Reports
Resolution: 8- or 4-samples/cycle
Event Summary
Storage: 100 summaries
Breaker History
Storage: 128 histories
Sequential Events Recorder
Storage: 1000 entries
Trigger Elements: 250 relay elements
Resolution: 0.5 ms for contact inputs
1/8 cycle for all elements
Processing Specifications
AC Voltage and Current Inputs
8000 samples per second, 3 dB low-pass analog filter cut-off frequency
of 3000 Hz
Digital Filtering
Full-cycle cosine and half-cycle Fourier filters after low-pass analog and
digital filtering
