Selec PID500 User Manual

SALIENT FEATURES
? Universal Input
17 user selectable types including signal inputs.
? Selectable lower display
User selectable lower display options enable quick setting of different
parameters such as Set points, Alarms, PID values, Tuning etc.
? Zone PID
4 programmable control zones.
? Outputs
In signal output models output is selectable as control output or
retransmission output.
? Special Modes
User selectable special modes
- Heat-Cool PID
- Auto/Manual
- Single point ramp/soak.
- Soft start.
4 Sensor break indication
4 Sensor error compensation
4 Programmable parameter lockouts
4 90 to 270 VAC/DC supply
4 Compliance-
4 IP66 front panel protection
Overview
1
Optional Features
4 Extra Alarm output
(0 to 10V, 0 to 5V, 0/4 to 20mA)
4 24 VAC/DC supply voltage models
4 Heater current monitoring
4 Motorised input
4 12 VDC output to drive SSR.
4 Linear DC outputs (Factory set)
4 RS-485 MODBUS communication
4 Remote set-point input
48 x 48
96 x 48
96 x 96

Selec PID500 Specifications

General

Mounting	Panel Mount
Operating Temperature	0 to 50°C
Input Type	Thermocouple, RTD
Control Type	PID, On/Off
Output Type	Relay, SSR
Supply Voltage	85 to 270 VAC
Display	Dual, 4-digit, 7-segment LED
Size	48 x 48 mm
Accuracy	±0.25% of F.S. ±1 digit
