Selec PID500 User Manual

2. INPUT
Thermocouple: J,K,T,R,S,C,E,B,N,L,U,W,Platinel II.
RTD: PT100.
Signal inputs: -5 to 56 mV, 0 to 10 VDC, 0 to 20 mA DC
(Programmable scale type)
200 ms.
O
1/0.1 for TC/RTD.
1/0.1/0.01/0.001 for Analog input.
(Decimal point position)
O
+0.25% of span or 1 whichever is greater.
(20min of warmup time). Cold junction calibration
o
accuracy in TC mode + 5 C.
OFF, 1 to 99 sec.
Led Status
Annunciators
Input
Sampling time
Resolution
Indication accuracy
Digital filtering
1. TECHNICAL SPECIFICATIONS
1. DISPLAY
Display
Main output (1)
Alarm output ( 2, 3)
Manual output (M)
Tune (T)
3
Specifications
3. OUTPUT
3.1. Control Output
Rating: 5A @250 VAC or 30 VDC.
Life expectancy: 100000 cycles at maximum load rating.
12 VDC.
Range: 0 -20 mA DC, 4-20 mA DC (Factory set)
Action: Control.
Update rate: PID Update - Every Cycle time.
Analog Output - 100 msec.
Maximum output load resistance: 500E.
Range: 0-5 VDC, 0-10 VDC.(Factory set)
Action: Control.
Update rate: PID Update - Every Cycle time.
Analog Output - 100 ms.
Minimum output load resistance: 10K.
Relay contact output
SSR drive voltage output
(optional)
Current output (Optional)
Voltage output (Optional)
PID500 - 48 X 48 - Dual 4 digit 7- segment LED.
Upper display : 10mm high Red (process value).
Lower display : 7mm high Green (selectable).
PID110 - 48x96 - Dual 4 digit 7- segment LED.
Upper display : 10mm high Red (process value).
Lower display : 7mm high Green (selectable).
PID330 - 96x96 - Dual 4 digit 7- segment LED.
Upper display : 14mm high Red (process value).
Lower display : 10mm high Green (selectable).

Selec PID500 Specifications

General

Mounting	Panel Mount
Operating Temperature	0 to 50°C
Input Type	Thermocouple, RTD
Control Type	PID, On/Off
Output Type	Relay, SSR
Supply Voltage	85 to 270 VAC
Display	Dual, 4-digit, 7-segment LED
Size	48 x 48 mm
Accuracy	±0.25% of F.S. ±1 digit
