Selec PID500 User Manual

6
Sensor type
Range
Sensor type
Range
J
o
- 200 to 750 C
E
K
o
- 200 to 1350 C
B
T
o
- 200 to 400 C
N
R
o
0 to 1750 C
L
S
o
0 to 1750 C
U
C
o
0 to 2300 C
W
Platinel II
o
0 to 1390 C
PT100
o
- 200 to 750 C
o
+149 to 1820 C
o
- 200 to 1300 C
o
- 200 to 600 C
o
- 200 to 900 C
o
0 to 2300 C
o
- 100 to 850 C
Signal inputs:
Input type
Linear mV
Voltage
Range
-5 to 56mV
0 to 10 VDC
CE.
As per BS EN 61010.
As per BS EN 61326.
IP66.
Compliance
LVD
EMC
Panel sealing
8. SAFETY AND EMC STANDARDS.
9. WEIGHT : PID500 : 195 gms ; PID110 : 250 gms ; PID330 : 295 gms
10. HOUSING : Flame retardant engineering plastic.
o
11. INPUT SENSOR RANGES (for 1 C resolution):
12. INPUT SELECTION JUMPER ASSIGNMENTS :
NOTE : Sensor selection to be done in Level 0 of programming also.
Short respective pins of JP1 as per the table given below for hardware
selection of input sensor types :
NOTE : The following parameters have been modified.
JP1
A
B
E D
C
4 - 20 mA
(BA)
TC / RTD / LIN (mV)
Input type
0 - 10V
JP1
(CB)
(ED)
A
B
E
D
C
A B
E
D
C
A
B
E
D
C
Current 0 to 20mA
Specifications

Selec PID500 Specifications

General

Mounting	Panel Mount
Operating Temperature	0 to 50°C
Input Type	Thermocouple, RTD
Control Type	PID, On/Off
Output Type	Relay, SSR
Supply Voltage	85 to 270 VAC
Display	Dual, 4-digit, 7-segment LED
Size	48 x 48 mm
Accuracy	±0.25% of F.S. ±1 digit
