Controller Programming
To be used in conjunction with the Controller Programming Instruction.
PROGRAMMING LINES
By setting all FUNCTION switches to ON and then pressing enter will set the system to
default. (See Controller function Programming for set up and manufactures default settings).
Note: If a Controller has already been set with an address this will be deleted.
Select the line number to program using the FUNCTION switches 1 - 5, note that position 6,
7 and 8 are always in the OFF position. (See Controller Programming Instruction).
Next using the DATA switches 1 to 4 set the Privacy time. For Call volume and Call type, set
DATA switches 5, 6 and 7 to the required positions. At this time, setting DATA switch 8 to
the ON position will program a Strobe, Sounder or both. (See Controller Programming Instruction).
Finally pressing the enter button will save the current Line information to memory. Continue until all
Lines are programmed.
LOCK RELEASE PROGRAMMING
Use the FUNCTION switches to select Entrance Panel 1 and the DATA switches to select
the number of seconds for the release duration. Select the lock release duration time using the
TIME SELECTION seconds chart. (See Controller Programming Instruction).
Repeat for Entrance Panel 2
TELEPHONE RING TIME FROM THE ENTRANCE PANEL
Use the FUNCTION switches to select Entrance Panel 1 and the DATA switches to select
the number of seconds for the ringing time duration. Select the ring time duration using the
TIME SELECTION seconds chart.(See Controller Programming Instruction).
Repeat for Entrance Panel 2
ENTRANCE PANEL TO TELEPHONE CALL DURATION TIME
Use the FUNCTION switches to select Entrance Panel 1 and the DATA switches to
select the number of seconds for the call duration time. Select the call duration time using the
TIME SELECTION seconds chart. (See Controller Programming Instruction).
Repeat for Entrance Panel 2
DELAY BEFORE DOOR ALARM ACTIVATION
Use the FUNCTION switches to select Entrance Panel 1 and the DATA switches to select
the number of minutes for the delay time. Select the Door Alarm delay duration time using the
TIME SELECTION minutes chart. (See Controller Programming Instruction).
Repeat for Entrance Panel 2
DOOR ALARM DURATION TIME
Use the FUNCTION switches to select Entrance Panel 1 and the DATA switches to select
the number of minutes for the alarm duration. Select the Door Alarm duration time using the
TIME SELECTION minutes chart. (See Controller Programming Instruction).
Repeat for Entrance Panel 2
If required, the System Controller can send serial data to a PC.
