5
Nr.
1 1
Antennen-
Hauptteil
2
A1
B1 1
Winkelhalterung
3B2 1
Hauptstütze
4B3 1
Fensterhalterung A
5B4 1
Fensterhalterung B
Fixierungshalterung A
Fixierungshalterung B
6B5 1
7B6 1
Symbol Teilename Abbildung Menge
8B7
1
Schraubenschlüssel
panner
Schachtelinhalt
SELFSAT-H21D+
SELFSAT-H30D+
