CONNECTORS

Connecting load cells to the indicator

● The indicator can connect with 4 load cells of 350Ω at most. Use the quick

disconnect connector

Quick Disconnect

DB9 Connection (9 pin Serial Connector)

The DB9 9 pin serial connector is used for different purposes depending on the

indicator model

● Figure 4 shows the pin assignment on the DB9 9 pin connector

DB9 SERIAL CONNECTOR PINOUT

DB9 Pin Description

DB9 Pin Denition Function

2 TXT Transmit Data

3 RXD Receive Data

5 GND Ground Interface
