Comfort technologydivisio
n
“MUSA Plus Eco
”
Electronic control for towel radiators
Rev. 02
–
Sept. 201
7
Selmo Electronic
Viia Pacinotti, 24 - 35030 Rubano (PD) Italy- Tel 049.8976761, Fax 049.8976085 - www.selmo.it
EN
Installation guide
For use by installer only
•The electronic control must be connected to the electric resistance only by
authorized personnel.
•Make sure that the power of the electric resistance does not exceed the maximum
power of the towel radiator
Example of heating element (Class II).
Thread
Insulation
Fastening area
2 Faston connectors 6.3x0.8mm
YES
WARNING:
Disconnect the power supply before proceeding with installation.
The installation has to be performed only by authorized personnel.
N
O
IMPORTANT: Pay attention to
the maximal length of the 19mm
connector (see picture above).
Longer connectors could damage
the device.
O-rin
g
0,
5
7,5
6
4 3
2 male connectors
6.38x0.8 mm
Max 19mm
Thread 1/2'
'
G
