Installation
Telephone installation
1. Connect one end of handset coil cord to the handset base and the other
end to the base unit (20).
2. Connect one end of the telephone line cord to the base unit at (19) and the
other end to the wall outlet. In case your house is not equipped with a
compatible wall outlet, you may need an adaptor, or you should consult
your distributor/retailer for assistance.
3. Insert the removable base, running up in the suitable guides.
4. Wall Mount
This telephone set can be mounted on wall. To prevent the handset from
falling, take out the handset guide, rotate it for 180 degree, and then
re-insert it into the original place.
For wall mounting works as follow:
- make on the wall n. 2 holes with a diameter of 5 mm each with an
apart distance and minimum distance from the surrounding surfaces,
as shown in Figure below,
- insert the 5 mm plugs into the holes
- fasten the screws to the plugs up to 5 mm from the surface of the wall
