9
MODEL
ANTIBES 15XS
S505XS
ANTIBES 20XS
S495XS
ANTIBES 25XS
S505XS
MAIORCA 25XS
S495XS
MAIORCA 30XS
S525XS
POWER
15HP/11KW 20HP/14.7KW 25HP/18.4KW 25HP/18.4KW 30HP/22KW
FULL THROTTLE RANGE
5000 5000 5500 6000 6000
PISTON DISPLACEMENT
489
BORE X STROKE
72/60
NUMBER OF CYLINDER
2 in a line
ENGINE TYPE
C
cle ei
ht 2 stroke
FUEL PUMP
N° 1 membrane
AVERAGE
78999
5
FUEL
mixture of 2% petrol with "SELVA OUTBOARD OIL - TC WII - oil
FUEL TANK
separated, lt. 23
IGNITION
C.D.I. -Electronic nautical with capacitive discharge, fully sealed capacitor discharge for each cylinder
SPARK LEAD
Automatic electronic programmed with the engine revolutions
MANUAL STARTING
manual with rope, which returns automatically on the pulley
ELECTRIC STARTING
standard with a
enerator 12V/ 70 W and current rectifier to rechar
e the batter
BOSCH W6B-CHAMPION L87Y DEGREE TERM.200
EXHAUST
bi-lateral and through propeller hub
COOLING
water cooling with forced circulation caused by a pump
PROPELLER
ratio 13/27 anti-weed with three blades and silent block incorporated
GEAR SHIFT LEVER
forward gear - neutral gear - reverse gear
REC.GEARBOX OIL
"SELVA OUTBOARD MOTOR GEARBOX OIL " 8O/90W (API GL-5 SAE 80/90w)
GEARBOX OIL QUANTITY
350 CC. / 320 gr.
TRIM ANGLE ADJUSTING
5 positions, which you can select through pin
SUSPENSIONS
silent block
DIST. PROP. BRACKETS
Normal shaft 570 - lon
shaft 695
REC. HEIGHT OF
Normal shaft 380/400 - lon
shaft 500/520
WEIGHT
normal shaft kg. 52 long shaft kg. 54
normal shaft kg.54 long shaft kg. 56
Selva joint stock CO reserve the right to change weight, construction, materials and characteristics without warning and without therefore have to change
the motors, which were built previously. See picture N. 15 for the dimensions
