LOCATION OF MAIN COMPONENTS
See picture 16
N° DESCRIPTION
1 Propeller
2 Propeller fixing nut
3 Water circulation warning
4 Back cowling lock lever cover
5 Tilt-up handle and air intake
6 Gear shift lever (R= reverse gear; N= neutral gear; F= forward gear)
7 Battery joint wires
8 Free lock lever
9 Fixing motor screws housing
10 Trim-angle adjusting rod
11 Motor data label
12 Hole for engine cleaning joint plug
13 Water inlet
14 Oil drain-plug hole
15 Oil-level plug hole
16 Anode
17 Throttle grip (model with manual start)
18 Throttle control adjustment (model with manual start)
19 Transport handle
20 Clamp to fix the motor
21 Steering connector
22 Engine stop switch (model with electric start)
23 Choke knob (model with manual start)
24 Fuel connector
25 Front cowling lock lever
26 Recoil starter handle (model with manual start)
27 Engine stop switch
28 Steering rod (model with manual start)
29 Steering adjustment
30 Anti-cavitation plate
