8
SPECIFICATIONS
MODEL ANTIBES 25 - S495 ANTIBES 30 - S505 MAIORCA 35 - S525
POWER
25HP/18.4KW 32HP/23,5KW 35,3HP/26Kw
FULL THROTTLE RANGE
5500 5500 6000
PISTON DISPLACEMENT
489 489 489
BORE X STROKE
72/60 72/60 72/60
NUMBER OF CYLINDER
2 in a line 2 in a line 2 in a line
ENGINE TYPE
Cycle eight 2 stroke
FUEL PUMP
N° 1 membrane pump
AVERAGE
8 9 9
FUEL
mixture of 2 % petrol with "SELVA OUTBOARD OIL - TC WII - oil
FUEL TANK
separated, lt. 23
IGNITION
C.D.I. -Electronic nautical with capacitive discharge, fully sealed capacitor discharge for each cylinder
SPARK LEAD
Automatic electronic programmed with the engine revolutions
MANUAL STARTING
manual with rope, which returns automatically on the pulley
ELECTRIC STARTING
standard with a generator 12V/ 70 W and current rectifier to recharge the battery
SPARK PLUGS
BOSCH W3AC - CHAMPION L78 heat range 275
EXHAUST
bi-lateral and through propeller hub
COOLING
water cooling with forced circulation caused by a pump
PROPELLER
ratio 13/27 anti-weed with three blades and silent block incorporated
GEAR SHIFT LEVER
forward gear - neutral gear - reverse gear
REC.GEARBOX OIL
"SELVA OUTBOARD MOTOR GEARBOX OIL " 8O/90W (API GL-5 SAE 80/90w)
GEARBOX OIL QUANTITY
350 CC. / 320 gr.
TRIM ANGLE ADJUSTING
5 positions, which you can select through pin
SUSPENSIONS
silent block
DIST. PROP. BRACKETS
Normal shaft 570 - lon
shaft 695
REC. HEIGHT OF
TRANSOMS (mm)
Normal shaft 380/400 - long shaft 500/520
WEIGHT
normal shaft kg. 52
long shaft kg. 54
normal shaft kg.54
long shaft kg. 56
