Never bind or entangle the cables of the remote control box.
They mustn't be bound with a bending ray inferior to 300 mm.
(12 feet).
The cables must be of the type C-2. Picture No.43
CONNECTION OF THE CABLES OF CONTROL
Side of the remote control box
To connect the control cables to the box you have to follow the following
instructions:
ß Remove the lower cover (6) of the remote control box by unscrewing
the two screws.
ß Put the control lever (1) in neutral position.
ß Screw completely the gear to connect the remote control box (9) to
the threaded extremity of the cables and fix them with the counter-
nut, paying attention not to tighten it too much.
ß Put the head of the gear-control lever in the pawl of the gear lever
(10) and insert the retaining ring (8).
ß Insert the head of the gas-control cable in the pawl of the accelerator
lever (11) and insert the retaining ring.
ß Fix the sheathing of the cables inserting the sheathing-retainer in its
housing.
ß Screw the lower cover. Picture No. 44
Remote control box fixation
After having connected the remote control cables, put the box in the
foreseen position and fix it with the screws.
Picture No.45
Connection side of the motor
Kit k40
To connect the control cables to the motor you have to use the kit k40
which is composed by:
1 sheathing retainer (2 parts)
2 connection for gears handle
3 connection for plate control gas
4 plate to fix the sheathing-retainer (2 parts)
5 cotter pin to fix the sheathing (2 parts)
