Step 3: Swing Wall Prep
Part 4
It is important to assemble the frame on a at, smooth surface.
I:Attachthetopboardineach(2756)SidingAssemblyto(2757)LTPostAssemblyand(2758)RTPost
Assemblywith4(S30)WoodScrewsperboard.(g.3.8and3.9)
J:Attachtheremainingboardsineach(2756)SidingAssemblyto(2757)LTPostAssemblyand(2758)RTPost
Assemblywith2(S0)TrussScrewsperboard.(g.3.8an3.9)
Fig. 3.9
Fig. 3.8
S30
x4
x4
8 x Wood Screw
20 x Truss Screw
S30
Hardware
S0
S30
2758
2757
2756
2756
TopBoard
RemainingBoards
x10
S0
x10
S0
S0
S30
