MODEL 1201CC PARTS LIST
NO DESCRIPTION PART NO. QUANTITY
1 Instruction Manual SMSZ48334A11 1
2
3 Rating Name Plate SMSZ48328A11 1
4 Machine Number Plate SMSZ48078B11 1
Machine Name Plate SMSZ48221A11 1
6 Label for Disassemble Prohibition SMSZ47966B11 1
7 MS43 Packing Complete Set SMSZ47345A01 1
8 Waste Bag M SMSZ46537A01 1
9 Waste Box SMSZ6470B11 1
Cover SMSZ8312A11 1
11 Upper Cover SMSZ1588C01 1
12 Plate for Protection Against Vibration-Large SMSZ45729B11 2
13 Plate for Protection Against Vibration-Middle SMSZ45730A12 4
14 Plate for Protection Against Vibration-Small SMSZ45731B11 1
Instruction Plate SMSZ31068B11 1
16 Upper Cover Rubber (Rear) SMSZ8193A12 1
17 Positioning Plate SMSZ30304F11 1
18 Spacer SMCP-403 3
19 STOP Button Reinforcement Plate SMSZ48065B11 1
Spacer SMASP-422 2
21 Operation Plate SMSZ31067A12 1
22 Display Window SMSZ47095C11 1
23 Reverse Button SMSZ47909A11 1
24 Stop Button SMSZ47908A11 1
Start Button SMSZ47907A11 1
26 Switch PC Board SMSZ31124B01 1
27 S/W Relay Wire SMSZ45702A01 1
28 Board Cover 2 SMSZ47999B11 1
29 Spacer SMSZBSP-408E 1
Spacer SMASP-418 3
31 Fireproofing Film Grommet SMC-30-SG-22A-UL 1
32 Shooting Plate Assembly SMSZ30957E01 1
33 Loading Slot Plate SMSZ31194B11 1
34 Loading Slot Cushion SMSZ46326B11 2
Loading Slot Shaft SMSZ45996E11
1
36 Stretch Spring SMSZ46057A11 1
37 Loading Slot SW Assembly SMSZ47055C01 1
38 Warning Plate SMSZ31069B11 1
39 Auto Start SMGP2A20 1
Waste Light Sensor Packing SMSZ44217B11 3
41 Loading Slot Relay Wire SMSZ45697A01 1
42 Ground Wire SMSZ4802602 1
