Sembdner RS 60 N

13

Filling the seed:

Before filling the seed into the sowing machine, the lawn mixture must be fully remixed since it may

have become separated or unsettled during its transport!

Setting the seed quantity:

The seed quantity per m² is set with the adjustable lever on the large dial at the front of the seed bin.

The dial’s numbers do not refer to grams, but are only reference points. At “0,” seed discharge is

blocked completely.

Determining the seed quantity per m²:

There are two options; the seed catcher bin (mounted over the pre-roller with two hinged flaps) must

first be pushed onto the seed deflector in both.

(1) Model RS 60 N measure a distance of 16.5 m and then set off.

Model RS 80 N measure a distance of 12.5 m and then set off.

Model RS 100 N measure a distance of 10.0 m and then set off.

In each case, this will result in a seed quantity for 10 m² in the seed catcher bin; the desired value is

determined and set by appropriately adjusting the seed dial.

(2) The seed bin has a V-belt pulley and a clutch which must be disengaged for the following. Pull out

the drive pin and give a quarter-turn to prevent reengagement. At the opposite side of the machine,

after opening the seed discharge, use the crank (found in the toolbox) on the agitator shaft to make

even rotations as follows:

Model RS 60 N 15½ rotations

Model RS 80 N 11½ rotations

Model RS 100 N 9 rotations

In each case, this will result in a seed quantity for 10 m² in the seed catcher bin; the desired value is

determined and set by appropriately adjusting the seed dial.

Do not forget to reengage the clutch.
