Senco PC0968 - Technical Specifications; Motor and Pump Specifications; Performance Ratings

15
SPECIFICATIONS
Model # PC0968
Motor
Horsepower 1.5 HP (Peak) 1 HP (Running)
Voltage 115
Amperage
8
Hz. 60
Phase Single
RPM 3450
Compressor Pump
Number of Cylinders
1
Compression Stage
1
Lubrication Lubeless
Crankcase Aluminum
Bearings Ball
Cylinder Aluminum/Steel Sleeve
Valves Reed-Single
Head Aluminum
Filter Insert
Motor/Pressure Switch Setting
Cut-out 135 PSI
Cut-in 105 PSI
Controls Start/Stop
Air tank
Capacity 2.5 gallon
Performance
CFM Air Displacement
4
CFM @ 90 PSI
2.2
Maximum Pressure
135 PSIG
Pump-up Time: 0-135 PSI 82 seconds
Recovery Time: 105-135 PSI 17 seconds
Weight
Net 38 lbs.
Dimensions
Basic LxWxH 16"x15"x13.5"
