Senco PC1001 - Specifications

15
SPECIFICATIONS
Model # PC 1001
Motor
Horsepower 2 Equivalent
Voltage 115
Amperage 15
Hz. 60
Phase Single
RPM 3400
Compressor Pump
Number of Cylinders 1
Compression Stage 1
Lubrication Splash
Oil Type Non-detergent
Crankcase Aluminum
Bearings Ball
Cylinder Steel sleeve inserts
Valves Reed-Single
Head Aluminum
Filter Canister
Motor/Pressure Switch Setting
Cut-out 116 PSI
Cut-in 87 PSI
Controls Start/stop
Air tank
Capacity 4.3 gallons
Performance
CFM Air Displacement 7.7
CFM @ 40 PSI 5.3
CFM @ 90 PSI 4.0
CFM @ 116 PSI 3.6
Maximum Pressure 116 PSI
Pump-up Time: 0-116 PSI 1 min., 10 sec.
Recovery Time: 90-116 PSI 15 seconds
Weight
Net 54 Ibs.
Shipping 56 Ibs.
Dimensions
Basic LxWxH 20"x14"x16"
Cubic Feet 2.6'
