Senco PC1005 - Specifications

15
SPECIFICATIONS
Model # PC 1005
Motor
Horsepower 1,0
Voltage 115
Amperage 12
Hz. 60
Phase Single
RPM 3400
Compressor Pump
Number of Cylinders 1
Compression Stage 1
Lubrication Oil-splah
Oil Type SENCO PC 0344
Crankcase Aluminium
Bearings Ball
Cylinder Aluminium + steel sleewer
Valves Reed-Single
Head Aluminium
Filter Canister
Motor/Pressure Switch Setting
Cut-out 125 PSI
Cut-in 95 PSI
Controls Pressure switch
Air tank
Capacity 2.5 gallon
Performance
CFM Air Displacement 4
CFM @ 40 PSI 2.9
CFM @ 100 PSI 2.4
CFM @ 125 PSI 2.2
Maximum Pressure 125 PSI
Pump-up Time: 0-125 PSI 1 min., 35 sec.
Recovery Time: 90-125 PSI 24 seconds
Weight
Net 37.5 lbs.
Shipping 40 lbs.
Dimensions
Basic LxWxH 22” x 9” x 18.5”
Cubic Feet 2.1’
