Senco PC1010 - Compressor Specifications

15
SPECIFICATIONS
Model # PC1010
Motor
Horsepower 1 HP (Peak) 1/2 HP (Running)
Voltage 115
Amperage
4
Hz. 60
Phase Single
RPM 3400
Compressor Pump
Number of Cylinders
1
Compression Stage
1
Crankcase Aluminum
Bearings Ball
Cylinder Aluminum
Valves Reed-Single
Head Aluminum
Filter Insert
Motor/Pressure Switch Setting
Cut-out 125 PSI
Cut-in 95 PSI
Controls Start/stop
Air tank
Capacity 1 gallon
Performance
CFM Air Displacement 1.4
CFM @ 40 PSI
1.0
CFM @ 90 PSI
0.7
CFM @ 100 PSI
0.6
Maximum Pressure
125 PSIG
Pump-up Time: 0-125 PSI 141 seconds
Recovery Time: 95-125 PSI 42 seconds
Weight
Net 20 lbs.
Dimensions
Basic LxWxH 14"x13"x10"
