SPECIFICATIONS
Model # PC 1010N
Motor
Horsepower
1 HP (peak) 1/2 HP (Running)
Voltage
115
Amperage 4
Hz. 60
Phase
Single
Compressor Pump
Number of Cylinders 1
Compression Stage 1
Crankcase Aluminum
Bearings Ball
Cylinder Aluminum
Valves Reed-Single
Head Aluminum
Filter
Insert
Motor/Pressure Switch Setting
Cut-out 135 PSI
Cut-in 105 PSI
Controls
Start / Stop
Air tank
Capacity
1 gallon
Performance
CFM Air Displacement
CFM @ 40 PSI
CFM @ 90 PSI
CFM @ 100 PSI
Maximum Pressure 135 PSIG
Pump-up Time: 0 -135 PSI 102 sec.
Recovery Time: 105 -135 PSI 27 seconds
Weight
Net 21 lbs.
Dimensions
Basic LxWxH 14”x 13” x10”
RPM
3400
1.4
1.0
0.7
0.6
