Senco PC1280 - Specifications

14
SPECIFICATIONS
Model # PC 1280
Motor
Horsepower
1.8 HP (peak) 1.5 HP (Running)
Voltage
120
Amperage 12
Hz. 60
Phase
Single
Compressor Pump
Number of Cylinders 1
Compression Stage 1
Crankcase Aluminum
Bearings Ball
Cylinder Steel
Valves Reed-Single
Head Aluminum
Filter
Plastic
Motor/Pressure Switch Setting
Cut-out 150 PSI
Cut-in 120 PSI
Controls
Start / Stop
Air tank
Capacity
6 gallon
Performance
CFM Air Displacement
CFM @ 40 PSI
CFM @ 90 PSI
CFM @ 100 PSI
Maximum Pressure 150 PSIG
Pump-up Time: 0-125 PSI 152 sec.
Recovery Time: 95-125 PSI 33 seconds
Weight
Net 38.6 lbs.
Dimensions
Basic LxWxH 17.1”x 16.3” x9”
RPM
2900
5.6
3.7
2.8
2.5
0-150 PSI
120-150 PSI
