10 Hoverprobe Refurbishment
3.1.2 SI9550
17. Remove old micro switch and air valve
from bracket (24).
18. Clean the bracket (24) and flatten both
sides of the new air-valve (29) with
sanding paper.
19. Stick 30mm VHB tape (30) onto the
bracket (24), put some drops of glue (31)
on the tape to hold the plastic valve.
20. Stick the air-switch (29)
onto the bracket (24) as
high as possible and equal
with the front surface, but
make sure there is no leak.
21. Place whole assembly in a
vice to set for 5 minutes.
Do NOT over tighten the
vice!
