4 Hoverprobe Refurbishment
2. Packing List
ITEM QTY DESCRIPTION
1 1 Hoverplate
3 1 Gasket
4 1 O Ring, 98*2.5, NBR70
5 1 Airplate
6 14 Screw torx LN1442, K40x14 stainless steel
8 3 Pillar, M5x70mm long, male to female, stainless steel
9 1 Probe tip
13 1 Weight cushion
14 1 Bearing
15 1 Bearing holder
22 100mm Plastic air pipe, polyurethane, 4mm pipe in o/d 4mm
25 1 2 pole lever – ONLY REQUIRED FOR SI9550
28 1 Microswitch – ONLY REQUIRED FOR SI9550
29 1 Micro air valve
29A 2 x 15 mm Heat shrink 6/2 adhesive black – ONLY REQUIRED FOR SI9550
30 2 x 30 mm VHB tape Acrylic foam – ONLY REQUIRED FOR SI9550
31 1 Loctite 480 glue – ONLY REQUIRED FOR SI9550
1
6
29A
14
4
15
3
13
9
22
28 29
22
25
8 31
30
