12 Hoverprobe Refurbishment
3.2 Final assembly
27. Place copper pipe (22) through
the weight and in to the air plate
air fitting (7).
28. Make sure the copper pipe (22) is
still connected to the air-valve
(29) without side tension.
29. Make sure that the micro switch is triggered before the air-valve is triggered.
30. Connect the banana plug wire to
the centre pillar (17) and tighten
the screw (18) gently.
