Seneca Z109REG2 - Power Supply; Environmental Conditions; Input; 3.3 Connections

ENGLISH 3/16
MI004202-E
Errors referred to maximum
measuring range:
Calibration
Error
Thermal
Coefficient
Linearity
Error
EMI
Voltage or current input
0.1%
0.01%/°K
0.05%
<1%
TC Input: J, K, E, T, N
0.1%
0.01%/°K
0.2°C
<1% (1)
TC Input: R, S
0.1%
0.01%/°K
0.5°C
<1% (1)
TC Input: B (2)
0.1%
0.01%/°K
1.5°C
<1% (1)
Cold junction compensation
(to TC Input)
2°C in ambient range from 0 to 50°C.
Potentiometer / Resistor Input
0.1%
0.01%/°K
0.1%
<1%
Thermoresistance RTD Input:
P 00, P 500, P 1000, N 100 (3)T T T I1
0.1%
0.01%/°K
0.02% (se t > 0°C)
0.05% (se t < 0°C)
<1% (4)
Voltage output (5)
0.3%
0.01%/°K
0.01%
(1) Influence of cable resistance 0.1 V/ .m W
(2) Output zero if t < 250 °C.
(3)All the values have to be calculated on the resistive value..
(4) Influence of cable resistance 0.005%/ max 20 .W W
(5) Values to be added to the errors of the selected input.
INSULATIONS 1500VA
STANDARDS
The module complies with the following standards:
EN61000-6-4 (electromagnetic emission,
in industrial environment)
EN61000-6-2 (electromagnetic immunity,
in industrial environment)
EN61010-1 (safety)
Notes:
- Use with copper conductor.
- Use in Pollution Degree 2 Environment
- Power Supply must be Class 2
- When supplied by an Isolated Limited Voltage and/or
Limited Current power supply, a fuse rated max 2.5 A
shall be installed in the field.
1500 VA insulating voltage is among:
- power supply
- analog input
- analog output / digital input/ output
3.3 CONNE IONCT S
USB Interface
Micro USB connector (frontal panel)
3.4 POWER SUPPLY
Supply Voltage
10-40 V , 19-28 V 50-60 Hz,C A through screw terminals: 2 – 3
Power supply unit
Classe 2
Power consumption
1.6 W @ 24 V with output 20 mA;C Max: 2.5 W
3.5 MODULE CASE
Case
PA6, black color
Dimensions
Width L=100mm; Height H=112mm; Depth W=17,5mm
Board terminals
Removable 3 way screw terminals: pitch 5.08mm, section 2.5mm
2
Protection class
IP20
3.6 ENVIRONMENTAL CONDITIONS
Operating
Temperature
-10°C – +60°C (UL: -10°C – +60°C)
2
3
4
5
6
USB
POWERSUPPLY
I / O
DIGITAL
1
UNIVERSAL
INPUT
ANALOG
OUT
10
11
12
9
8
7
1500 VA
