Senix CS4QL-L1 - PARTS LIST

28 WWW.SENIXTOOLS.COM
No. Part # Description Qty.
1 199004000716 Rear handle 1
2 199096000114 Initiator 1
3 103001000353 Engine Head Assembly 1
4 199001000548 End cap assembly 1
5 202030001847 Cover 1
6 199064000065 Carburetor 1
7 199077000019 Air Filter 1
8 202030001848 Air filter cover 1
9 8342-966004-
0000000
Rear handle damping
spring
2
10 8206-965105-
0000000
Long set screw 2
11 8SJJD05-20D Pan Head Grooved
Screw
4
12 8SJJD05-40D Torx screw in pan head 2
13 8NG-08D Hex Flange Nut 2
14 8SJJD05-12D Pan Head Grooved
Screw
1
No. Part # Description Qty.
15 8SJJB50-12D Pan Head Grooved
Screw
2
16 8SJJB50-30D Pan Head Slotted
Internal Pattern Screw
1
17 208043000002 Oiler 1
18 8261-966001-
0000000
Spark plug wrench 1
19 8261-902101-
0000000
Torx wrench 1
20 243-0175 Guide bar 1
21 243-0036 Saw chain 1
22 202009000169 Guide bar cover
(scabbard)
1
PARTS LIST
