Product overview
6
Product overview
Overview of the EM 2000/EM 2050 receiver
The EM 2050 twin receiver has the same operating elements as the EM 2000 receiver. All information contained
in this instruction manual refers to both receivers.
Operating elements – front panel Operating elements – rear panel
쐃 Rack mount “ear”
쐇 Headphone output,
¼” (6.3 mm) jack socket ( )
쐋 Headphone volume control
쐏 button, backlit
쐄 Infra-red interface
쐂 Display panel, backlit in orange
쐆 Jog dial
쐊 STANDBY button:
operation indication
(red backlighting),
ESC function (cancel)
쐎 3-pin mains socket
쐅 Cable grip for mains cable
쐈 Audio output
(TRANS BAL AF OUT),
¼” (6.3 mm) jack socket,
transformer balanced
쐉 Audio output
(TRANS BAL AF OUT),
XLR-3M socket,
transformer balanced
씈 LED (yellow) for network activity
indication
씉 LAN socket (ETHERNET RJ 45)
씊 Type plate
씋 Antenna input II (ANT II RF IN)
with booster supply voltage,
cannot be switched off, short-
circuit proof, BNC socket
씌 Antenna output II (ANT II RF OUT),
BNC socket
씍 Antenna output I (ANT I RF OUT)
BNC socket
씎 Antenna input I (ANT I RF IN) with
booster supply voltage, cannot be
switched off, short-circuit proof,
BNC socket
A
B
50/60Hz 0.25A +18dBu MAX ETHERNET RJ-45
RF IN RF INRF OUT
ANT II ANT I
B A
TRANS-BAL
AF OUT B
+18dBu MAX ETHERNET RJ-45
TRANS-BAL
AF OUT A
100 - 240V
DC OUT 11V/250mA DC OUT 11V/250mA
543.200
**2000** **2000**
B.Ch: 20.64
PEAK
MUTE
EQ:
+ 12dB
P
-10
040
30
20
10
-20
-30
-40
AF
RF
MHz
543.200
B.Ch: 20.64
PEAK
MUTE
EQ:
+ 12dB
P
-10
040
30
20
10
-20
-30
-40
AF
RF
MHz
True Diversity Receiver EM 2050
SKM2000 SKM2000
50/60Hz 0.25A +18dBu MAX ETHERNET RJ-45
RF IN RF INRF OUT
ANT II ANT I
B
TRANS-BAL
AF OUT B
100 - 240V
DC OUT 11V/250mA DC OUT 11V/250mA
DESIGNED IN AND MADE IN GERMANY
IC: 2099A- XXXXXXX
ART. NO.: XXXXXX
TRUE DIVERSITY RECEIVER
FMO
EM 2000
SER. NO.: XXXXXXXXXX
CUS
R
FREQ. RANGE-Xw:
0682
X/X XXX-XXX MHz
GOST
DESIGNED IN AND MADE IN GERMANY
IC: 2099A- XXXXXXX
ART. NO.: XXXXXX
TRUE DIVERSITY RECEIVER
FMO
EM 2000
SER. NO.: XXXXXXXXXX
CUS
R
FREQ. RANGE-Xw:
0682
X/X XXX-XXX MHz
GOST
543.200
B.Ch: 20.64
PEAK
MUTE
EQ:
+ 12dB
P
-10
0
40
30
20
10
-20
-30
-40
AF
RF
MHz
True Diversity Receiver EM 2000
**2000**
SKM2000
씈
쐇쐋쐏쐄 쐂 쐆쐊
쐉쐈씎씍씌씋
씊씉
쐉쐈쐅쐎
쐃쐇쐋쐏쐄쐂쐆쐊쐃
쐃쐇쐋쐏쐄쐂쐆쐊쐃
쐈쐅쐎
씈씉
씈
씎씍씌씋
씊씉
쐉
A
B
EM 2050
EM 2000
A B
