Control elements
Signal from LED display :
 Headband

Normal/bypass sliding switch
 Connection for audio cable
 Audio cable
 ON/OFF button
 VOLUME – button
 TalkThrough button
 LED (red/green)
 VOLUME + button
 Ear cushions
 Battery compartment
LED Meaning
red NoiseGard
2.0 is switched on (see page 11)
green TalkThrough is switch on (see page 12)
flashing Batteries or rechargeable batteries almost empty (see page 7)










