4
Specifications
Transducer principle pre-polarized condenser
microphone
Frequency response 40 … 20,000 Hz
Pick-up pattern super-cardioid
Sensitivity (free field, no load at 1 kHz) 3 mV/Pa
Nominal impedance (at 1 kHz) 200 W (balanced)
100 W (unbalanced)
Min. terminating impedance 1 kΩ
Max. sound pressure level at 1 kHz 150 dB/SPL
Phantom powering 12–52 V / 3 mA
Connector XLR-3
Temperature range 0 °C to +40 °C
Dimensions Ø 47 x L 193 mm
Weight 311 g
The polar diagram and the frequency response curve D can be found on
the cover pages.
The XLR-3 connector assignment E can be found on the cover pages.
