Sennheiser e604 - Specifications; Connector Assignment

4
Specifications
Transducer principle dynamic
Frequency response 40 ... 18,000 Hz
Pick-up pattern cardioid
Sensitivity
(free field, no load at 1 kHz) 1,8 mV/Pa
Nominal impedance (at 1 kHz) 350 Ω
Min. terminating impedance 1 kΩ
Connector XLR-3
Dimensions Ø 33 x L 59 mm
Weight 60 g
The polar diagram and the frequency response curve C can be found on
the cover pages.
Connector assignment
12
3
1
2
3
+ +
1
2
3
XLR 6.3 mm
+
+
12
3
XLR
+
XLR
1
2
3
6.3 mm
+
+
balanced
XLR
XLR
+
