6
Product overview
Product overview
Overview of the SKM 300 G3 radio
microphone
쐃 Microphone head (interchangeable)
쐇 Name and pick-up pattern of the microphone head
(not visible here, see page 4)
쐋 MIC button
쐏 Body of radio microphone
쐄 Battery compartment (not visible from outside)
쐂 Display panel, backlit in orange
쐆 Infra-red interface
쐊 Antenna
쐎 Color-coded protection ring;
available in different colors
쐅 Operation and battery status indicator, red LED
(lit = ON/flashing = LOW BATTERY)
쐈 Charging contacts
쐉 Multi-function switch:
(DOWN), (UP) and (SET)
씈 ON/OFF button
with ESC function (cancel)
쐋
쐎
쐏
쐄
쐂
쐆
쐊
씈
쐈
쐈
쐅
쐈
쐎
쐉
쐇
