Sennheiser EVOLUTION WIRELESS EW 100 - Preparing the Devices for Use; EM 100 Receiver

51
! " #$%
&
' ( ) * +
, LC display
- ! button (UP)
. " button (DOWN)
/ SET button
0 POWER (ON/OFF) button
1 Cable grip for power supply DC cable
2 DC socket for connection of mains unit (DC-IN)
3 AF output,
1
/
4
” (6.3 mm) jack socket (AF OUT BAL/UNBAL)
4 AF output level control (AF LEVEL)
* Antenna input II (ANT II), BNC socket
+ Antenna input I (ANT I), BNC socket
5 Preparing the devices for use
EM 100 receiver
