EK 100 pocket receiver
! Antenna
" Red LED for operation and battery status indication (ON/LOW BAT)
% Green LED for RF signal indication (RF)
$ Cover plate for battery compartment
# Cover plate for display and operating controls
1 AF output (AF OUT), 3.5 mm jack socket
2 AF output level control
3 SET button
4 ON/OFF button
* LC display
+ " button (DOWN)
5 ! button (UP)
