61
&
(
! "
) *
Inserting and changing the battery
! Slide the cover of the battery compartment 3 in the direction of the
arrow until it clicks audibly and open the cover.
! Insert the 9 V PP3 battery (IEC 6 LR 61). Please observe correct polarity
when inserting the battery.
! Close the battery compartment.
Plugging the transmitter onto the microphone
! Plug the transmitter’s XLR-3 connector ! onto the microphone’s
XLR-3 socket.
! Tighten the locking ring ".
Note:
The transmitter uses the microphone body as an antenna – therefore
only microphones with a metal casing should be used for best signal
transmission.
Switching the transmitter on/off
! Press the ON/OFF button 4 to switch the transmitter on. The red
LED * lights up.
! To switch the transmitter off, press the ON/OFF button until “OFF”
appears on the display. You can then release the button. The red LED
goes off.
Muting the transmitter
Use the MUTE switch & to noiselessly mute the transmitter’s audio signal
(this switch does not switch off the transmitter).
