82
Overall device EM 100 !EK 100
Power supply 10.5–16 V DC,
!9 V PP3 battery (IEC 6 LR 61)
nominal voltage 12 V DC !
Power consumption (operating time) ≤ 200 mA !≤ 75 mA (4–6 h)
Dimensions [mm] 212 x 145 x 38 !110 x 65 x 22
Weight approx. 1100 g !approx. 255 g
Tran
s
mitter
s
RF characteristics SK 100 !SKP 100 !SKM 100
RF output power at 50 Ω typ. 30 mW
Antenna length [mm] 518 – 550 MHz: 130
!
630 – 662 MHz: 110 !
740 – 772 MHz: 90 !
790 – 822 MHz: 90 !
838 – 870 MHz: 80 !
AF characteristics
Max. input voltage MICRO: 1.8 V
rms
!2.9 V
rms
!–
(at peak dev., 1 kHz
AF
) LINE: 2.4 V
rms
Overall device
Power supply 9 V alkaline PP3 battery (IEC 6 LR 61)
Max. power consumption at nom. voltage ≤ 60 mA
Operating time > 8 h !> 8 h !> 8 h
Dimensions [mm] 110 x 65 x 22 !105 x 43 x 43 !Ø 50 x 225
Weight approx. 255 g !approx. 195 g !approx. 450 g
Mi
c
rophone
s
ME 2 !ME 3 !ME 4
Transducer principle condenser !condenser !condenser
Sensitivity 20 mV/Pa !1.6 mV/Pa !40 mV/Pa
Sound pressure 130 dB SPL !150 dB SPL ! 120 dB SPL
Pick-up pattern omni-directional !super-cardioid !cardioid
MD 835 !MD 845 !ME 865
Transducer principle dynamic !dynamic !condenser
Sensitivity 1.5 mV/Pa !1 mV/Pa !3 mV/Pa
Sound pressure 150 dB SPL !154 dB SPL ! 144 dB SPL
Pick-up pattern cardioid !super-cardioid !super-cardioid
