Sennheiser SET100 - Connector Assignment Details

41
31 2
23
1
;
;
1
2
;;;;;;;;;;;;;
;;;;;;;;;;;;;
3 4
4
2
1
3
solder side
5
U174/U jack plug
1 Microphone Lo
2 Audio Hi
3 Microphone Hi
4 Audio Lo
PJ-068 jack plug
1 Not assigned!
2 Microphone Hi
3 Microphone Lo
1
/
4
” (6.35 mm) stereo jack plug
1 Audio Hi left
2 Audio Hi right
3 Audio Lo
Connector assignment
XLR-5 connector
1 Audio Hi
2 Audio Lo
3 Microphone Hi
4 Microphone Lo
5—
