TECHNICAL DATA
Mode selection switch:
I
mono channel 1
II
mono channel 2
∞
stereo channel 1+2
Modulation FM
Carrier frequencies channel 1: 2.3 MHz
channel 2: 2.8 MHz
Nominal deviation
±
50 kHz
Emitting diodes 11
Pre-emphasis 50
µ
s
Audio frequency response 30 - 18,000 Hz
THD
(1 kHz and nominal deviation)
≤
1 %
Signal-to-noise ratio
≥
74 dBA
rms
≥
63 dB as per CCIR 468
Volume control automatic
AF connection 3.5 mm ø jack plug with
adaptor to
1
/
4
”(6.3 mm)
RF output for connection
of infra-red radiators 3.5 mm mono jack socket
Input voltage for
nominal deviation 45 mV- 4 V
Automatic on/off function yes
Input voltage for automatic
on/off function > 45 mV
Operation indicator green LED
Operating voltage 24 - 27 V DC
Current consumption 180 mA
Power consumption (standby) approx. 3.5 VA
Dimensions approx. 118 x 25 x 90 mm
Weight approx. 140 g
Subject to alterations. Errors and omissions excepted.
