SENSORWORX SWX-101-D Series User Manual

INSTALLATION CONT.
MOUNTING
 Designed to mount in 1-gang wall box with 3.28” hole spacing
 Units also can share multiple gang wall boxes with other devices
** SENSOR FACE IS FIELD REMOVABLE IN ORDER TO CHANGE COLORS. CONTACT FACTORY FOR ADDITIONAL FACES
FRONT SIDE
SUPPLIED MOUNTING SCREWS
FOR MOUNTING TO
SINGLE GANG SWITCH BOX
1.39”
0.94”
KEY INSTALLATION
FEATURE
25-40% SHALLOWER
THAN OTHER WALL
SWITCH SENSORS
BREAK-OFF
BRACKET EARS
BREAK-OFF
BRACKET EARS
LED INDICATOR
RAISE
ON/OFF BUTTON
LOWER
SENSOR FACE**
2.74”
1.69”
** SENSOR FACE IS FIELD REMOVABLE IN ORDER TO CHANGE COLORS. CONTACT FACTORY FOR ADDITIONAL FACES
DIMMING APPLICATION TABLE
MODEL #
DETECTION TYPE DEFAULT OPERATING MODE
1,2
PIR ACOUSTIC NAME DESCRIPTION
SWX-101-D • Partial On Auto-On to 50%
SWX-103-D • Vacancy Manual On to Last Level
SWX-111-D • Partial On Auto-On to 50%
SWX-121-D • • Partial On Auto-On to 50%
SWX-123-D • • Vacancy Manual On to Last Level
SWX-131-D • • Partial On Auto-On to 50%
1. ALL MODES ARE ENERGY CODE COMPLIANT
2. MODES ON ALL UNITS ARE FIELD CONFIGURABLE
DIMMING APPLICATION OVERVIEW
