APPENDIX 1
PROGRAMMING STEPS FOR THE 101/301 BOARD
Step number
Description Example Description Remote
Prgrm?
Error Messages:
E1: does not exist
E2: duplicate found
E3: system is full
E5: format error
00 Terminate Programming 00+# Yes
01 Set Password 01+nnnnnn+# Yes
02 Verify Password 02+nnnnnn+# 1=nnnnnn matches current
setting, 0 = no match
No
03 Set Dialing Type 03+n+# Sets dialing type to tones
(1), pulses (0)
Yes
03 Verify Dialing Options 03+# (1/0 for tone/pulse) No
04 Set Rings Before Answer 04+n+# Sets rings before answer to
0 <=n <=9
Yes
04 Verify Rings Before Answer 04+# If 0, don’t answer No
05 Set Visitor Talk Time 05+n+# 015 <=n <255 Yes
05 Verify Visitor Talk Time 05+# No
06 Set PBX Digit 06+n+# Set PBX digit Yes
06 Verify PBX Digit 06+# Display PBX digit No
06 Erase PBX Digit 06+101010+# Erase PBX digit Yes
07 Program Relay Activation Time 07+r1+r2+# Sets relay 1 to r1 (2 digits)
and relay 2 to r2 (2 digits)
Yes
07 Verify Relay Activation Time 07+# No
08 Set Directory Code Length 08+n+# Sets code length to 1 <= 4
digits 1<=n <=4
Yes
08 Verify Directory Code Length 08+# No
09 Program Directory Code and
Phone Number
09+d[ddd]+t[ttt
tttttttt]+#
Sets code d[ddd] (1-4 digits)
to t[ttttttttttt] up to 12 digits
Yes
09 Verify Directory Code and
Phone Number
09+d[ddd]+# No
10 Erase Directory Code and
Phone Number
10+d[ddd]+# Erases dir code d[ddd] (1-4
digits)
Yes
11 Erase All Directory Codes and
Phone Numbers
11+101010+# Erases all dir codes Yes
12 Set # of wrong entry codes 12+n+# Sets incorrect entry codes
allowed to 0 <=n <=9
Yes
12 Verify # of wrong entry codes 12+# If n=0, strikes and out is
disabled
No
13 Program Entry Code 13+eeee+# Sets entry code eeee with
relay action code 1
Yes
13 Program Entry Code + Relay
Action Code (RAC)
13+eeee+r+# Sets entry code with
specified relay action code
‘r’
Yes
14 Erase Entry Code 14+eeee+# Erases entry code eeee (4
digits)
Yes
15 Erase All Entry Codes 15+101010+# Erases all entry codes Yes
52 System Reset
69 Set Feedback 69+# No
7r (see Relay Action
Codes, next page)
Relay Management Functions 7+r+# Performs the specified relay
action ‘r’
Yes
